Carbon Air Filter Spraying And Scattering Machine
Machine photo Production Process Using a new melt-blown technology, the hot melt adhesive is sprayed on the bottom surface of the entire material in a fibrous form, and activated carbon is scattered on the spray surface through a material spreading device to achieve adsorption, and it is...
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Machine photo


Production Process
Using a new melt-blown technology, the hot melt adhesive is sprayed on the bottom surface of the entire material in a fibrous form, and activated carbon is scattered on the spray surface through a material spreading device to achieve adsorption, and it is composited by spraying the material. It eliminates the need for pre-stirring the traditional carbon and rubber powder, and spraying it through the high-power drying tunnel to dissolve and heat-press the molding process. (The amount of glue and powder can be set according to user needs to realize the automatic feeding function of activated carbon powder).
STANDARD TECHNICAL PARAMETERS CUSTOMIZABLE)
Model: | KT-SPR |
Maximum Material Width: | 1200-2000mm |
Machine Roller Width: | from 1400mm to 220mm |
Gluing Amount: | 5-80g/m2 |
Machine speed: | 3-35m/min |
Power: | 30-50KW |
Electric Current and Voltage: | Customizable |
Net Weight: | 12000-20000KGS |
Dimension: | 11800 x 2900 x 3600mm |
Usage
It is suitable for all kinds of non-woven fabrics, clothing lining fabrics and other fabrics to scatter hot-melt powder and activated carbon powder into the oven to melt and penetrate into the lining for bonding. It can be achieved through hot-melt adhesive powders such as PE, EVA, EVAL, PES, etc. All kinds of fusible interlining cloth dusting effect required.
Applicable industry
Automotive interiors, filter consumables, home furnishing, building materials, decoration and other industries
